Toggleable checkbox with text label. More...

#include <checkbox.h>

Inheritance diagram for TuiCheckBox:

[legend]

Collaboration diagram for TuiCheckBox:

[legend]

Public Member Functions
	TuiCheckBox (const String &text=String(), ObjectBase *parent=nullptr)

void	setText (const String &text)

const String &	text () const

bool	isChecked () const

void	setChecked (bool checked)

void	toggle ()

Size2Di32	sizeHint () const override
	Returns the preferred size. Override in subclasses.

Public Member Functions inherited from TuiWidget
	TuiWidget (ObjectBase *parent=nullptr)
	Constructs a TuiWidget.

virtual	~TuiWidget ()
	Destructor.

const Rect2Di32 &	geometry () const
	Returns the geometry relative to parent.

void	setGeometry (const Rect2Di32 &rect)
	Sets the geometry.

int	x () const
	Returns the X coordinate relative to parent.

int	y () const
	Returns the Y coordinate relative to parent.

int	width () const
	Returns the width.

int	height () const
	Returns the height.

Size2Di32	size () const
	Returns the size.

const Size2Di32 &	minimumSize () const
	Returns the minimum size constraint.

void	setMinimumSize (const Size2Di32 &size)
	Sets the minimum size constraint.

const Size2Di32 &	maximumSize () const
	Returns the maximum size constraint.

void	setMaximumSize (const Size2Di32 &size)
	Sets the maximum size constraint.

TuiSizePolicy	sizePolicy () const
	Returns the size policy.

void	setSizePolicy (TuiSizePolicy policy)
	Sets the size policy.

bool	isVisible () const
	Returns true if the widget's own visibility flag is set.

bool	isEffectivelyVisible () const
	Returns true if the widget and all its ancestors are visible.

void	show ()
	Shows the widget.

void	hide ()
	Hides the widget.

void	setVisible (bool visible)
	Sets visibility.

bool	isEnabled () const
	Returns true if the widget is enabled.

void	setEnabled (bool enabled)
	Sets enabled state.

TuiFocusPolicy	focusPolicy () const
	Returns the focus policy.

void	setFocusPolicy (TuiFocusPolicy policy)
	Sets the focus policy.

bool	hasFocus () const
	Returns true if this widget has focus.

void	setFocus ()
	Requests focus for this widget.

void	update ()
	Marks the widget as needing a repaint.

bool	isDirty () const
	Returns true if the widget needs repainting.

void	clearDirty ()
	Clears the dirty flag.

TuiLayout *	layout () const
	Returns the layout, if one is set.

void	setLayout (TuiLayout *layout)
	Sets the layout for this widget.

Point2Di32	mapToParent (const Point2Di32 &p) const
	Maps a local point to the parent's coordinate system.

Point2Di32	mapFromParent (const Point2Di32 &p) const
	Maps a parent point to local coordinates.

Point2Di32	mapToGlobal (const Point2Di32 &p) const
	Maps a local point to global (screen) coordinates.

Point2Di32	mapFromGlobal (const Point2Di32 &p) const
	Maps a global (screen) point to local coordinates.

virtual Size2Di32	minimumSizeHint () const
	Returns the minimum size hint. Override in subclasses.

Public Member Functions inherited from ObjectBase
	ObjectBase (ObjectBase *p=nullptr)
	Default ObjectBase constructor.

virtual	~ObjectBase ()
	Destructor. Emits aboutToDestroy, detaches from parent, and destroys children.

ObjectBase *	parent () const
	Returns the parent object, if one. nullptr if none.

void	setParent (ObjectBase *p)
	Sets the parent of this object. If the object already has a parent, it will be removed as a child from the old parent and added as a child to the new one.

const ObjectBaseList &	childList () const
	Returns a list of children of this object.

template<typename... Args>
int	registerSlot (Slot< Args... > *slot)
	Registers a slot with this object and assigns it an ID.

EventLoop *	eventLoop () const
	Returns the EventLoop this object is affiliated with.

void	moveToThread (EventLoop *loop)
	Changes the EventLoop affinity of this object.

int	startTimer (unsigned int intervalMs, bool singleShot=false)
	Starts a timer on this object's EventLoop.

void	stopTimer (int timerId)
	Stops a timer previously started with startTimer().

template<typename... Args>
PROMEKI_NAMESPACE_BEGIN void	connect (Signal< Args... > signal, Slot< Args... > slot)

Protected Member Functions
void	paintEvent (TuiPaintEvent *e) override
	Called to paint the widget. Override in subclasses.

void	keyEvent (KeyEvent *e) override
	Called on keyboard input. Override in subclasses.

void	mouseEvent (MouseEvent *e) override
	Called on mouse input. Override in subclasses.

void	focusInEvent (Event *e) override
	Called when the widget gains focus.

void	focusOutEvent (Event *e) override
	Called when the widget loses focus.

Protected Member Functions inherited from TuiWidget
virtual void	resizeEvent (TuiResizeEvent *e)
	Called when the widget is resized. Override in subclasses.

void	event (Event *e) override
	Event dispatch override.

Protected Member Functions inherited from ObjectBase
ObjectBase *	signalSender ()
	Returns the ObjectBase that emitted the signal currently being handled.

virtual void	timerEvent (TimerEvent *e)
	Called when a timer fires for this object.

Additional Inherited Members
Public Types inherited from ObjectBase
using	SlotVariantFunc = std::function< void(const VariantList &)>
	Function type for invoking a slot with a list of Variants.

Static Public Member Functions inherited from ObjectBase
static const MetaInfo &	metaInfo ()
	Returns the MetaInfo for the ObjectBase class.

template<typename... Args>
static void	connect (Signal< Args... > signal, Slot< Args... > slot)
	connects a signal and slot together. This function assumes both the signal and slot exist in a ObjectBase or derived object

Public Attributes inherited from ObjectBase
Signal< ObjectBase * >	aboutToDestroySignal = Signal< ObjectBase * >(this, aboutToDestroySignalName)

Static Public Attributes inherited from ObjectBase
static constexpr const char *	aboutToDestroySignalName = PROMEKI_STRINGIFY( aboutToDestroy ) "(" PROMEKI_STRINGIFY_ARGS( ObjectBase * ) ")"

static SignalMeta	aboutToDestroySignalMeta = SignalMeta(metaInfo(), aboutToDestroySignalName)

Detailed Description

Toggleable checkbox with text label.

Displays as [x] Text when checked or [ ] Text when unchecked. Supports keyboard activation (Enter/Space) and mouse click to toggle. Emits the toggled signal when the checked state changes.

Member Function Documentation

◆ focusInEvent()

void TuiCheckBox::focusInEvent ( Event * e )

overrideprotectedvirtual

Called when the widget gains focus.

Reimplemented from TuiWidget.

◆ focusOutEvent()

void TuiCheckBox::focusOutEvent ( Event * e )

overrideprotectedvirtual

Called when the widget loses focus.

Reimplemented from TuiWidget.

◆ keyEvent()

void TuiCheckBox::keyEvent ( KeyEvent * e )

overrideprotectedvirtual

Called on keyboard input. Override in subclasses.

Reimplemented from TuiWidget.

◆ mouseEvent()

void TuiCheckBox::mouseEvent ( MouseEvent * e )

overrideprotectedvirtual

Called on mouse input. Override in subclasses.

Reimplemented from TuiWidget.

◆ paintEvent()

void TuiCheckBox::paintEvent ( TuiPaintEvent * e )

overrideprotectedvirtual

Called to paint the widget. Override in subclasses.

Reimplemented from TuiWidget.

◆ sizeHint()

Size2Di32 TuiCheckBox::sizeHint ( ) const

overridevirtual

Returns the preferred size. Override in subclasses.

Reimplemented from TuiWidget.

The documentation for this class was generated from the following file:

include/promeki/tui/checkbox.h
